Chapter 4. Removing a FRU or CRU
Service tools
The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving
the product models as described by this publication. Prepare them before you service the product.
Table 6. Service tools
Service tool and consumable
Model applicability
Screw driver (Phillips head) (PH1/PH01)
X
Screw driver (Torx head) (T5)
Screw driver (Torx head) (T30)
Pry tool 1 X
Tweezers (conductive)
X
Tweezers (isolated)
Suction cup
Hexagonal socket
Silicone grease
Acetate tape X
Polyamide tape
Mylar tape
Electrical tape
Double-sided tape
Conductive tape
Eraser
Heat gun
Brown brush
Notes:
• T30 screw drivers are used to service the new Intel Xeon CPUs.
• Hexagonal sockets are used to remove antenna connectors.
• Silicone grease is applied to the CPU and heatsink surfaces to eliminate air gaps.
General guidelines
When removing or replacing a FRU, ensure that you observe the following general guidelines:
1. Do not try to service any computer unless you have been trained and certified. An untrained person runs
the risk of damaging parts.
2. Begin by removing any FRUs that have to be removed before replacing the failing FRU. Any such FRUs
are listed at the beginning of each FRU replacement procedure. Remove them in the order in which they
are listed.
© Copyright Lenovo 2020 27

Lenovo IdeaPad 3 Specifications

General

Color name	Business Black
Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
Numeric keypad	Yes
Keyboard layout	QWERTY
Pointing device	Touchpad
Keyboard backlit	No
Keyboard language	Italian
Panel type	TN
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	220 cd/m²
Native aspect ratio	16:9
Processor cache	4 MB
Processor cores	2
Processor model	N4020
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor boost frequency	2.8 GHz
Internal memory	4 GB
Memory clock speed	2400 MHz
Memory form factor	On-board
Internal memory type	DDR4-SDRAM
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express 3.0
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MMC, SD, SDHC, SDXC
Number of SSDs installed	1
Battery capacity	35 Wh
Battery life (max)	14 h
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 600
On-board graphics card family	Intel® UHD Graphics
Audio system	Dolby Audio
Speaker power	1.5 W
Privacy type	Privacy shutter
Front camera resolution (numeric)	0.3 MP
Password protection type	HDD, Power on, Supervisor
AC adapter power	45 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
HDMI version	1.4b
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	-
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Sustainability certificates	ENERGY STAR, RoHS
Motherboard chipset	Intel SoC

Weight and Dimensions

Depth	253.4 mm
Width	362.2 mm
Height	19.9 mm
Weight	1700 g
