Chapter
3.
Identifying FRUs
(CRUs)
Locate
FRUs
and
CRUs
The
exploded
illustrations
help
Lenovo
service
technicians
identify
FRUs
or
CRUs
that they
may
need
to
replace
when
servicing
a
customer’s
computer.
Figure 1.
IdeaPad 4G
(14
″
,
05),
IdeaPad
14m
4G
2021
and IdeaPad
14m 4G
2021
DM
exploded
view
© Copyright
Lenovo 2020
23
28
30
