Lenovo IdeaPad 5 15ABA7 User Manual

Screw specifications Number of screws
M2 x L3.5 4
Step 3. Pry up the latches and then remove the lower case.
Figure 6. Remove the lower case.
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Lower case
Remove the battery pack
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 34
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove two screws, release the speaker cable from the cable guide and then remove the battery
pack.
Figure 7. Remove two screws and remove the battery pack
Chapter 4. Removing a FRU or CRU 35

Lenovo IdeaPad 5 15ABA7 Specifications

General

Graphics	Integrated AMD Radeon Graphics
Operating System	Windows 11 Home
Display	15.6" FHD (1920x1080)
RAM	8GB / 16GB DDR4
Storage	256GB / 512GB / 1TB SSD
Battery	57Wh
Weight	1.85 kg
Ports	HDMI, SD card reader
Wireless	Wi-Fi 6
