Lenovo IdeaPad 5 15ALC05 User Manual

Left
Figure 4. IdeaPad 5 (14″, 05) - left view
Figure 5. IdeaPad 5 (15″, 05) - left view
1. Power connector*
Connect to power with the included power cord and ac power
adapter.
Note: Some models do not have an individual power connector. They
use the USB-C connector to charge instead. Please refer to the actual
product.
2. Charging light
Indicate whether the computer is connected to ac power.
• Solid white: Connected to ac power; battery capacity 91%–100%
• Solid amber: Connected to ac power; battery capacity 1%–90%
• Off: Not connected to ac power
4 User Guide

Lenovo IdeaPad 5 15ALC05 Specifications

General

Graphics	Integrated AMD Radeon Graphics
Weight	1.66 kg (3.66 lbs)
Processor	AMD Ryzen 5 5500U
Display	15.6" FHD (1920x1080) IPS
RAM	8GB DDR4
Storage	256GB SSD
Operating System	Windows 10 Home
Ports	1 x USB-C 3.2 Gen 1, HDMI, headphone/mic combo jack, SD card reader
Wireless	Wi-Fi 6, Bluetooth 5.0
