Lenovo IdeaPad 5 Pro 14ACN6 Hardware Maintenance Manual

Screw specifications Number of screws
M2.0 x L4.0 2
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Battery pack
Remove the solid-state drive (SSD)
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove one screw.
Figure 6. Remove one screw
Screw specifications Number of screws
M2.0 x L2.0 1
Step 3. Remove the SSD by pulling it away from the slot.
Figure 7. Remove the SSD by pulling it away from the slot
30 Hardware Maintenance Manual

Lenovo IdeaPad 5 Pro 14ACN6 Specifications

General

Processor	AMD Ryzen 5 5600U / Ryzen 7 5800U
Brightness	300 nits
Graphics	Integrated AMD Radeon Graphics
Battery	56.5Wh
Webcam	720p HD
Display	14-inch
RAM	8GB DDR4
Storage	512GB SSD
Operating System	Windows 10 Home
Weight	1.38 kg
Audio	Dolby Audio, 2x 2W speakers
Ports	HDMI, SD card reader, Audio jack
Wireless	Wi-Fi 6, Bluetooth 5.1
Display Resolution	2240 x 1400
