Lenovo IdeaPad L340 Series Hardware Maintenance Manual

31
Lenovo IdeaPad Miix 2 8
1020 Battery pack
For access, remove this FRU:
• “1010 LCD cover” on page 31
DANGER
Onlyusethebatteryspecifiedinthepartslistforyourcomputer.Anyother
battery could ignite or explode.
Figure 2. Removal steps of battery pack
Disconnect the battery connector in the direction shown by arrow
1
, then
remove the six screws
2
.
2
2
2
2
2
2
1
Step Screw (quantity) Color Torque
2
M1.6 × 3.0, Battery to Bezel (6) Black 1.0 ~ 1.5kgf*cm

Lenovo IdeaPad L340 Series Specifications

General

Operating System	Windows 10 Home
Graphics	NVIDIA GeForce GTX 1650
Display	15.6" FHD (1920 x 1080) IPS
RAM	16GB DDR4
Storage	512GB SSD
Battery Life	Up to 9 hours
Ports	2 x USB 3.1, USB-C, HDMI, Headphone / Microphone Combo
Wireless	802.11 AC (2x2) / Bluetooth® 4.2
