Lenovo System x3650 M5 Product Guide

System x3650 M5 8
The x3650 M5 servers include the following items:
Statement of Limited Warranty

Important Notices

Rack Installation Instructions

Documentation CD that contains the Installation and User's Guide

System x Enterprise Slides Kit

2.8 m C13-C14 power cord (one for models with one power supply and two for models with two power

supplies)
Note: Cable Management Arm (CMA) is not included. See the "Rack options" section for ordering
information.
Standard models
Table 2 lists the standard models of the x3650 M5.
Table 2. Standard models (Part 1)
MTM# Intel Xeon processor†
(2 maximum)
Memory
(RDIMMs)
RAID Drive
bays
(std /
max)
Drives Onboard
NIC
I/O
slots
(std /
max)*
Optical
drive
Power
supply
(std /
max)
Models announced May 2015
5462-N2x 1x E5-2660 v3 10C 2.6GHz
25MB 2133MHz 105W
1x 16GB
2133MHz
M5210
2GB Flash
8x 2.5"
HS / 20
Open
bay
4x GbE 3 / 9 Optional 1x 750 W
HS / 2
5462-P2x 1x E5-2667 v3 8C 3.2GHz
20MB 2133MHz 135W
1x 16GB
2133MHz
M5210
2GB Flash
8x 2.5"
HS / 20
Open
bay
4x GbE 3 / 9 Optional 1x 900 W
HS / 2
5462-Q2x 1x E5-2697 v3 14C 2.6GHz
35MB 2133MHz 145W
1x 16GB
2133MHz
M5210
2GB Flash
8x 2.5"
HS / 20
Open
bay
4x GbE 3 / 9 Optional 1x 900 W
HS / 2
# The letter "x" in the Machine Type Model (MTM) represents a country-specific letter (for example, the EMEA MTM
is 5462-A2G, and the US MTM is 5462-A2U). Ask a Lenovo representative for specifics.
† Processor detail: Processor quantity and model, cores, core speed, L3 cache, memory speed, TDP.
* With one processor, only two standard PCIe slots (Slots 0 and 4) can be used (Slot 5 requires the second
processor). If a RAID controller is present, it occupies one of the standard PCIe slots (Slot 0).

Lenovo System x3650 M5 Specifications

General

Tcase	72.6 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor code	SR207
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	12
Processor codename	Haswell
Motherboard chipset	Intel® C612
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	85 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
Intelligent Platform Management Interface (IPMI) support	Yes
HDD size	- \
RAID levels	1, 5, 10, 50
HDD interface	-
Optical drive type	DVD Super Multi
Internal drive bays	8
Supported HDD sizes	2.5 \
Total storage capacity	- GB
Maximum storage capacity	100 TB
Number of HDDs installed	0
Supported storage drive interfaces	SAS, Serial ATA
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	1536 GB
Memory layout (slots x size)	1 x 16 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
PCI Express slots version	3.0
Compatible operating systems	Microsoft Windows Server \\r Red Hat Enterprise Linux\\r SUSE Linux Enterprise Server\\r VMware vSphere
Trusted Platform Module (TPM) version	2.0
Chassis type	Rack (2U)
Power supply	550 W
Graphics card	G200eR2
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Processor ARK ID	83352
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 3050 m
Storage temperature (T-T)	5 - 45 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	8 - 85 %
Maximum graphics card memory	16 MB
On-board graphics card model	Not available

Weight and Dimensions

Depth	800 mm
Width	446 mm
Height	87 mm
Weight	19000 g
