Lenovo ThinkPad L390 User Manual

The latest compliance information is available at:
https://www.lenovo.com/compliance
Regulatory labels
Depending on your country or region, you can find the government-required regulatory information through
one of the following methods:
• On a physical label attached to the outside of your computer shipping carton
• On a physical label attached to your computer
• Through an electronic-label screen (E-label screen) preinstalled on your computer
To access the E-label screen, do one of the following:
• Restart the computer. When the logo screen is displayed, press F9. The E-label screen is displayed.
• Restart the computer. When the logo screen is displayed, press Enter or tap the prompt to enter the
Startup Interrupt menu. Then, press F9 or tap the Regulatory Information option. The E-label screen is
displayed.
Korean E-label notice
TCO certification
To obtain the TCO certification information for your computer, go to:
https://www.lenovo.com/tco-cert
Export classification notice
This product is subject to the United States Export Administration Regulations (EAR) and has an Export
Classification Control Number (ECCN) of 5A992.c. It can be re-exported except to any of the embargoed
countries in the EAR E1 country list.
Lenovo product service information for Taiwan
Taiwan precautionary vision statement
警語：使用過度恐傷害視力
注意事項：
• 使用30分鐘請休息10分鐘。
• 2歲以下幼兒不看螢幕，2歲以上每天看螢幕不要超過1小時。
Eurasian compliance mark
96 L390, L390 Yoga, S2 4th Gen, and S2 Yoga 4th Gen User Guide

Lenovo ThinkPad L390 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
LED backlight	Yes
Display diagonal	13.3 \
Display brightness	250 cd/m²
Native aspect ratio	16:9
Bus type	OPI
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1528
Processor threads	8
Processor codename	Whiskey Lake
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	16
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
Memory upgrade note	Additional memory sold separately
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
On-board graphics card ID	0x3EA0
Discrete graphics card model	Not available
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Battery capacity	45 Wh
Battery life (max)	14.61 h
Audio chip	Realtek ALC3287
Speaker power	2 W
Audio decoders	Dolby Audio Premium
Number of built-in speakers	2
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Password protection type	BIOS, HDD, Power on, User
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
Front camera signal format	720p
WWAN	Not installed
Antenna type	2x2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
HDMI version	1.4b
Charging port type	USB Type-C
USB 2.0 ports quantity	0
Sustainability certificates	RoHS, ENERGY STAR
Pointing device	ThinkPad UltraNav
Processor ARK ID	149091
Intel TSX-NI version	0.00
Processor package size	46x24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Motherboard chipset	Intel SoC

Weight and Dimensions

Depth	224.2 mm
Width	321.8 mm
Height	18.8 mm
Weight	1460 g
