Lenovo ThinkPad L390 User Manual

Supervisor password
The supervisor password protects the system information stored in UEFI BIOS. When entering the BIOS
menu, enter the correct supervisor password when you are prompted by the icon
. You also can press
Enter to skip the password prompt. However, you cannot change most of the system configuration options in
UEFI BIOS.
If you have set both the supervisor password and power-on password, you can use the supervisor password
to access your computer when you turn it on. The supervisor password overrides the power-on password.
Hard disk passwords
The hard disk password prevents unauthorized access to the data on the storage drive. When a hard disk
password is set, you are prompted to type a correct password each time you try to access the storage drive.
To set the hard disk password, select one of the following types:
• User hard disk password only
When a user hard disk password is set without a master hard disk password, the user must enter the user
hard disk password to access files and applications on the storage drive.
• Master hard disk password + User hard disk password
The master hard disk password is set and used by a system administrator. It enables the administrator to
access any storage drive in a system or any computer connected in the same network. The administrator
can also assign a user hard disk password for each computer in the network. The user of the computer
can change the user hard disk password as desired, but only the administrator can remove the user hard
disk password.
When prompted to enter a hard disk password, press F1 to switch between the master hard disk password
and user hard disk password .
Attention: Record your hard disk password and store it in a safe place. If you forget the hard disk password,
Lenovo cannot reset your passwords or recover data from the storage drive. You must take your computer to
a Lenovo reseller or a marketing representative to have the storage drive replaced. Proof of purchase is
required, and a fee will be charged for parts and service.
Note: The hard disk password is not available in the following situations:
• A Trusted Computing Group (TCG) Opal-compliant storage drive and a TCG Opal management software
program are installed in the computer, and the TCG Opal management software program is activated.
• An eDrive storage drive is installed in the computer preinstalled with the Windows 10 operating system.
Set, change, and remove a password
Before you start, print these instructions.
1. Restart the computer. When the logo screen is displayed, press F1 to enter the BIOS menu.
2. Select Security ➙ Password by using the arrow keys.
3. Select the password type. Then, follow the on-screen instructions to set, change, or remove a
password.
You might want to record your password and store it in a safe place. Otherwise, if you forget the password,
you have to take your computer to a Lenovo reseller or a marketing representative to have the password
34
L390, L390 Yoga, S2 4th Gen, and S2 Yoga 4th Gen User Guide

Lenovo ThinkPad L390 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
LED backlight	Yes
Display diagonal	13.3 \
Display brightness	250 cd/m²
Native aspect ratio	16:9
Bus type	OPI
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1528
Processor threads	8
Processor codename	Whiskey Lake
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	16
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
Memory upgrade note	Additional memory sold separately
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
On-board graphics card ID	0x3EA0
Discrete graphics card model	Not available
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Battery capacity	45 Wh
Battery life (max)	14.61 h
Audio chip	Realtek ALC3287
Speaker power	2 W
Audio decoders	Dolby Audio Premium
Number of built-in speakers	2
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Password protection type	BIOS, HDD, Power on, User
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
Front camera signal format	720p
WWAN	Not installed
Antenna type	2x2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
HDMI version	1.4b
Charging port type	USB Type-C
USB 2.0 ports quantity	0
Sustainability certificates	RoHS, ENERGY STAR
Pointing device	ThinkPad UltraNav
Processor ARK ID	149091
Intel TSX-NI version	0.00
Processor package size	46x24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Motherboard chipset	Intel SoC

Weight and Dimensions

Depth	224.2 mm
Width	321.8 mm
Height	18.8 mm
Weight	1460 g
