T
able
55.
Removal
steps
of
LCD
panel
and
LCD
cable
2
2
3
3
1
1
Step
Screw
(quantity)
Color
T
orque
2
M2
×
3
mm,
wafer-head,
nylon-coated
(2)
Black
0.167
Nm
(1.7
kgfcm)
3
M2.5
×
5
mm,
wafer-head,
nylon-coated
(2)
Black
0.392
Nm
(4
kgfcm)
4
ThinkPad
SL400,
SL400c,
SL500,
and
SL500c
137
144
146
