2 Features:
• back emf-feature (constant speed)
• acceleration and deceleration seperately adjustable
• adjustable maximum speed
• Programming on Main
• multi unit capability (advanced consisting)
• function outputs A and B may be configured in many ways: depending on direction (F0),
output A forward active, output B reverse active or individually, output A reacts on F0, output
B reacts on F1
• outputs can be dimmed
• Marslight, Gyrolight, Strobe, Double Strobe
• Function outputs D and C:
• mapping to F1 through F8; blinking; Ditchlight
• Operation on standard DC systems (analogue operation) possible. This feature can be
disabled.
3 Installing the LE1025 via cable connection (Abb. 1, p.3)
Please note which motor connection is linked to the right rail pickups and which to the left. If you do
this you will not have to try out which decoder cable needs to be soldered to which motor connection
to achieve the desired direction of travel.
After removing the original connections to the motor brushes, the motor brushes must be potential-
free and completely isolated from both tracks. This means that they may not be connected in any
