32 Information LE1835
7.1 Resetting the decoder
If you wish to reset all the decoder CVs to the ex-works setting, enter 33 in CV8. The CVs of a
connected S.U.S.I. module are not reset in this case!
8 Table of supported CVs
CV
Value /
Bit
Meaning
Ex-works
setting
1
1-127 Basis locomotive address
This is the number which is used to call up locomotives in the
Digital plus by Lenz
®
system. The use of range 1-99 is
recommended for operation with Digital plus by Lenz
®
devices.
When writing this CV, CV19 (multiple traction address) is
automatically deleted in the decoder and Bit 6 (use of
extended address) is deleted in CV29.
3
2
0-31
Minimum starting voltage
0
3 Starting delay
4
4 Braking delay
4
5
2-10 Maximum speed:
The speed actually achieved depends on the motor
characteristic.
10
7
-
Version number
1
8
-
Manufacturer’s identification
99
17
192-231
Extended locomotive address, high-order Byte
0
18
0-255
Extended locomotive address, low-order Byte
0
