33
E
19
1-99
Multiple traction address
0
29
Bit
Settings 1
1 (0) Direction of motion
0 normal: locomotive drives forwards if the arrow on the
manual control points up.
1 interchanged: locomotive drives forwards if the arrow on the
manual control points down.
0
2 (1) Running-notches mode:
0 Operation with 14 or 27 running notches.
This setting is chosen for all digital systems which do not
support the 28 running-notches mode.
1
1 Operation with 28 or 128 running notches.
This setting is chosen for digital systems which support the
28/128 running-notches mode.
3 (2) Operational mode:
0 Locomotive only runs in digital operation.
1 Locomotive runs both in digital and conventional operation,
flying splice possible.
1
4-5 (3-4) Not used 0
6 (5) 0 Decoder uses basic address (from CV1)
1 Decoder uses extended address (from CV17 and CV18)
0
7-8(6-7) Not used 0
