2 Accessory Decoder LS 100/110
Whats new in the upgraded LS100/110?
A push button and an LED have been added to the
LS100/110 to make programming easier. Direct CV mode is
now supported in service mode and a selectable flashing rate
has been added.
LED:
Whenever the LS100/110 has received information destined
for it, the LED will light up for a certain amount of time. This
allows you to very easily verify that your LS100/110 is
receiving information, and thus is correctly connected. If you,
for instance, have called up the turnout address on the hand
held controller and press the + or - keys, and keep them
pressed, then the LED will flicker or stay lit. If you release the
key, then the LED will also go out again. If this is not the case,
then you may have selected the wrong address on the LH100,
or the connection from the LV101 to the LS100/110 is not
correct.
The LED is also used as a display during programming with
the push button.
Push button:
The push button allows you to reprogram the address of an
installed LS100/110. You can also reset it to the factory
settings. The LED here serves to indicate the programming
process.
Selectable flashing rate:
In the previous version, the flashing rate was permanently
preset to 2 Hz. Now you have a range of 4 to 0.5 Hz.
available.
Special note
Accessory decoders LS100 and LS110 share this operation
manual. Unless noted, the text applies to the LS100 as well as
LS110. When describing features, connections, operational
steps, etc. that apply to only one of the accessory decoders,
only the decoder in question is named.
