Accessory Decoder LS 100/110 3
DIGITAL plus
Specifications of LS100/LS110
Up to 4 function devices each with a twin output can be
connected to each LS100/LS110. Power for these function
devices can by supplied by the track power or through an
external power supply. Each function device output can have its
characteristics individually set (by programming). In this way you
can program each output with a variable pulse duration, a
variable flashing operation or to a constant operation,. This
allows the direct connection of lightbulbs or LEDs without
additional relays.
The LS100 also has a connection for the feedback bus of the
DIGITAL plus system. If the feedback bus is connected, then the
position of turnouts can be sent back to the system when using
suitable turnout drives. It is then possible to display a turnout
being thrown by either DCC or by hand.
Electrical specifications:
Supply voltage:
8 - 18V AC or pulsing DC
8 - 25V pure DC (battery, lab power supply).
Current load capacity:
individual
output:
1.7A continous,
3 A peak (max. 20 sec.)
whole
decoder:
1.7A continous, as the sum of all
outputs.
3A peak (max. 20 sec.)
More about settings the outputs
Pulse output:
Pulse output means that the output is on (active) for at least as
long as a switching command is sent to LS100/LS110. The
switching command is for example sent to LS100/LS110 as
long as you keep the ‘+’ or ‘-’ key pressed on LH100.
The time that the function device output remains active after
releasing the key—the pulse duration—is determined by a
programmed numeric value. If during the activation time of this
