26 Information STANDARD+ V2 Decoder
2 Installing the decoder via cable connection (Abb. 1, p. 3.)
Please note which motor connection is linked to the right rail pickups and which to the left. If you do
this you will not have to try out which decoder cable needs to be soldered to which motor
connection to achieve the desired direction of travel.
After removing the original connections to the motor brushes, the motor brushes must be potential-
free and completely isolated from both tracks. This means that they may not be connected in any
way to the chassis or to the rail pickups of the locomotive. Bear in mind that a connection like this is
sometimes made simply when the chassis is put back!
Please contact a service centre if you are in any doubt as to whether all necessary preconditions for
the installation are fulfilled!
First connect the decoder to the pickups of the locomotive:
red cable to the pickups which are on the right-hand side of the locomotive in relation to the
direction of travel
black cable to the pickups which are on the left-hand side of the locomotive in relation to the
direction of travel
Then connect the decoder to the motor connections:
orange cable to the motor connection previously connected to the right pickups
grey cable to the motor connection previously connected to the left pickups.
Now connect the functions. Ex-works default settings for the functions are configured as follows:
Function outputs A and B as direction-dependent outputs reacting to F0. This configuration can be
altered as desired.
If you wish to use the function outputs in their initial configuration, connect the outputs as follows:
