SF01U 37
P10 TB-13A FUNCTION SELECT
This selects the function of terminal TB-13A. Closing TB-13A to TB-2 (or opening in the case of
settings 7 and 10) activates the selected function. The following functions can be selected:
01 NONE: Disables the TB-13A function.
02 0-10 VDC: Selects a 0-10 VDC signal (at TB-5) as the AUTO speed reference input.
03 4-20 mA: Selects a 4-20 mA signal (at TB-25) as the AUTO speed reference input.
04 PRESET SPEED #1: Selects PRESET SPEED #1 as the AUTO speed reference. The
drive will operate at the frequency programmed into Parameter 31.
05 RUN REVERSE: Close TB-13A to TB-2 to RUN in the reverse direction, and open to
STOP. This setting forces TB-12 to act as RUN FWD, requiring a maintained contact to
RUN in the forward direction. TB-1 must be closed to TB-2 for this function to operate.
06 START REVERSE: Momentarily close TB-13A to TB-2 to START the drive in the reverse
direction. Momentarily open TB-1 to TB-2 to STOP. This setting forces TB-12 to act as
START FWD, requiring a momentary contact to START in the forward direction.
07 EXTERNAL FAULT: Sets TB-13A as a normally closed external fault input. If TB-13A is
open with respect to TB-2, the drive will fault.
08 REMOTE KEYPAD: Selects the optional remote keypad as the control source. Refer to
Parameter 14 - CONTROL.
09 DB FAULT: Sets TB-13A as a dynamic braking fault input when using the optional dynamic
braking module. When this input is activated by the dynamic braking module, the drive
will trip into a "dF" fault and the motor will coast to a stop. Refer to the manual included
with the Dynamic Braking option.
10 AUXILIARY STOP: When TB-13A is opened with respect to TB-2, the drive will decelerate
to a STOP (even if STOP METHOD is set to COAST) at the rate set into Parameter 42
- ACCEL/DECEL #2.
11 ACCEL/DECEL #2: Selects the acceleration and deceleration time programmed into
Parameter 42 - ACCEL/DECEL #2.
NOTE
In order for the RUN REVERSE and START REVERSE functions to operate,
Parameter 17 - ROTATION DIRECTION must be set to FORWARD AND
REVERSE (02).
