SF01U 41
P20 DECELERATION TIME
This parameter sets the deceleration rate for all of the speed reference sources (keypad, speed
pot, 4-20 mA, 0-10 VDC, jog, MOP, and preset speeds). This setting is the time to decelerate
from BASE FREQUENCY to 0 Hz. If the drive is set for COAST TO STOP (setting 01 or 02 in
Parameter 04), this parameter will have no effect when a STOP command is given.
P21 DC BRAKE TIME
This determines the length of time that the DC braking voltage is applied to the motor. The
DC BRAKE TIME should be set to the lowest value that provides satisfactory operation in
order to minimize motor heating.
P22 DC BRAKE VOLTAGE
This sets the magnitude of the DC braking voltage, in percentage of the nominal DC Bus
voltage (DC Bus = input AC voltage X 1.414). The point at which the DC braking is activated
depends on the selected STOP METHOD (Parameter 04):
If COAST WITH DC BRAKE is selected, the DC braking is activated after a time delay of up
to 2 seconds, depending on the output frequency at the time of the STOP command. In this
case, the DC braking is the only force acting to decelerate the load.
If RAMP WITH DC BRAKE is selected, braking is activated when the output frequency reaches
0.2 Hz. In this case, the drive decelerates the load to a near stop and the DC braking is used
to bring the load to a final stop.
P23 MINIMUM FREQUENCY
This sets the minimum output frequency of the drive for all speed reference sources except
the PRESET SPEEDS (Parameters 31-37).
When using a 0-10 VDC or 4-20 mA analog speed reference signal, this parameter also sets
the drive speed that corresponds to the minimum analog input (0 VDC or 4 mA).
NOTE
If this parameter is changed while the drive is running, the new value will not
take effect until the drive is stopped.
P24 MAXIMUM FREQUENCY
This sets the maximum output frequency of the drive for all speed reference sources, and is used
with MINIMUM FREQUENCY (Parameter 23) to define the operating range of the drive.
When using a 0-10 VDC or 4-20 mA analog speed reference signal, this parameter also sets
the drive speed that corresponds to the maximum analog input (10 VDC or 20 mA).
NOTE
• On drives equipped with the High Output Frequency option, this parameter
can be set up to 999.9 Hz, depending on carrier frequency (parameter 02).
• If this parameter is changed while the drive is running, the new value will
not take effect until the drive is stopped.
