P41 LOAD SCALING
This scales the analog output signal at TB-30 and/or TB-31 when they are configured for a
load output. This setting is the load (in %) that is indicated when the output signal measures
10 VDC.
Example: A 0-10 VDC signal is required to indicate 0-150% load. Setting this parameter to
150% will yield 10 VDC at 150% load.
P42 ACCEL / DECEL #2
This parameter sets the second acceleration and deceleration rate of the drive. To activate
this acceleration and deceleration rate, use terminal TB-13A, TB-13B or T-13C. TB-13A and
TB-13B can be set to AUXILIARY STOP which will cause the drive to decelerate to a stop
according to the time programmed in this parameter. TB-13C can be set to ACCEL/DECEL
#2, which causes the drive to accelerate and decelerate according to the time programmed
in this parameter.
P43 SERIAL ADDRESS
If a serial link is being used to communicate with multiple drives, each drive must be given a
different address (from 1 to 247) so that an individual drive in the network can be accessed.
P44 PASSWORD
This allows the PASSWORD to be changed to any number between 000 and 999. Setting
PASSWORD to 000 disables the password function.
NOTE
The factory default password is 225
P47 CLEAR FAULT HISTORY
01 MAINTAIN: Maintains the FAULT HIST ORY (Parame ter 50) entries for
troubleshooting.
02 CLEAR: Erases the FAULT HISTORY (Parameter 50) entries.
P48 PROGRAM SELECTION
This is used to select whether the drive will operate according to the user settings or the optional
OEM default settings, and to reset the parameters to default settings. Refer to Section 13.2.
01 OPERATE WITH USER SETTINGS: The drive will operate according to the user
settings. Operation in USER mode allows the parameter values to be changed to suit
any application.
02 OPERATE WITH OEM DEFAULTS: The drive will operate according to the optional OEM
default settings, which configure the drive for a specific application. When operating in
OEM mode, the parameter values can be viewed, but not changed. If an attempt is made
to change a parameter setting, the display will flash “GE”. If the drive is not programmed
with OEM default settings, the display will flash “GF” if this option is selected.
03 RESET OEM: Resets the user parameters to the OEM default settings. If the drive is
not programmed with OEM default settings, the display will flash “GF” if this option is
selected.
