SF01U 57
B.3 SETPOINT REFERENCES
The following references can be used to adjust the process setpoint:
1. Keypad ( and buttons)
2. 0-10 VDC signal (from speed pot or other source)
3. 4-20 mA signal
4. Preset Setpoints (using Preset Speeds #4 and #5)
5. MOP (using terminals 13B and 13C)
NOTE
The setpoint reference and the PI feedback cannot be the same signal. If the
drive is mistakenly programmed so that the setpoint reference is the same as the
feedback reference, the setpoint reference will default to the and buttons.
B.4 ADDITIONS TO THE STANDARD PARAMETER MENU
NO. PARAMETER NAME RANGE OF ADJUSTMENT
FACTORY
DEFAULT
06
13
TB-14 OUTPUT
TB-15 OUTPUT
MIN ALARM (11), MAX ALARM (12),
MIN/MAX ALARM (13), INV MIN ALARM (14),
INV MAX ALARM (15), INV MIN/MAX ALARM (16)
HIGH (01)
10 TB-13A FUNCTION KEYPAD SETPOINT (12) NONE (01)
11 TB-13B FUNCTION KEYPAD SETPOINT (09) NONE (01)
12 TB-13C FUNCTION KEYPAD SETPOINT (10) NONE (01)
45 SPD AT MIN SIGNAL MINIMUM FREQ - 999.0 Hz 0.0 Hz
46 SPD AT MAX SIGNAL MINIMUM FREQ - 999.0 Hz 60.0 Hz
61 PI MODE
OFF (01)
NORMAL 4-20 mA (02), NORMAL 0-10 VDC (03)
REVERSE 4-20 mA (04), REVERSE 0-10 VDC (05)
OFF (01)
62 MIN FEEDBACK 0.0 - 999.0 0.0
63 MAX FEEDBACK 0.0 - 999.0 100.0
64 PROPORTIONAL GAIN 0.0 - 99.9% 5.0%
65 INTEGRAL GAIN 0.0 - 99.9 SEC 0.0 SEC
66 PI ACCEL/DECEL 0.0 - 999.0 SEC 20.0 SEC
67 MIN ALARM 0.0 - 999.0 0.0
68 MAX ALARM 0.0 - 999.0 0.0
69 0-10 VDC FEEDBACK (VIEW ONLY) (N/A)
70 4-20 mA FEEDBACK (VIEW ONLY) (N/A)
71 ACTUAL FREQUENCY (VIEW ONLY) (N/A)
74 ANALOG INPUT FILTER 1-1000 2
75 SLEEP THRESHOLD 0.0 - 360 Hz 0.0 Hz
76 SLEEP DELAY 0.0 - 300 SEC 30.0 SEC
77 SLEEP BANDWIDTH MIN FEEDBACK - MAX FEEDBACK 0.0
