38 SF01U
P11 TB-13B FUNCTION SELECT
This selects the function of terminal TB-13B. Closing TB-13B to TB-2 (or opening in the case
of setting 08) activates the selected function. The following functions can be selected:
01 NONE: Disables the TB-13B function.
02 0-10 VDC: Selects a 0-10 VDC signal (at TB-5) as the AUTO speed reference input.
03 4-20 mA: Selects a 4-20 mA signal (at TB-25) as the AUTO speed reference input.
04 PRESET SPEED #2: Selects PRESET SPEED #2 as the AUTO speed reference. The
drive will operate at the frequency programmed into Parameter 32.
05 DECREASE FREQUENCY: Decreases the speed setpoint when using the MOP function.
Refer to Section 10.6.
06 JOG FORWARD: Jog in the forward direction. In this mode, the drive will JOG at the
speed programmed into Parameter 32 - PRESET SPEED #2.
07 JOG REVERSE: Jog in the reverse direction. In this mode, the drive will JOG at the
speed programmed into Parameter 32 - PRESET SPEED #2.
WARNING!
When operating in JOG mode, the STOP terminal (TB-1), the AUXILIARY
STOP function (see setting 08), and the STOP key on the optional remote
keypad WILL NOT stop the drive. To stop the drive, remove the JOG
command.
JOG REVERSE will operate the drive in reverse rotation even if ROTATION
DIRECTION (Parameter 17) is set to FORWARD ONLY.
08 AUXILIARY STOP: When TB-13B is opened with respect to TB-2, the drive will decelerate
to a STOP (even if STOP METHOD is set to COAST) at the rate set into Parameter 42
- ACCEL/DECEL #2.
NOTE
If the drive is commanded to JOG while running, the drive will enter JOG
mode and run at PRESET SPEED #2. When the JOG command is removed,
the drive will STOP.
