40 SF01U
P15 SERIAL LINK
This parameter configures the drive for serial communications. The options are listed by
baud rate, number of data bits, parity, number of stop bits, and whether the watchdog timer
is enabled or disbabled.
The watchdog timer will stop the drive after 10 seconds of no serial activity to safeguard against
a failed serial link. During set-up or troubleshooting, it may be useful to disable the watchdog
timer, but is it not recommended to run normally without the watchdog timer.
WARNING!
Automatic starting of equipment may cause damage to equipment and/or
injury to personnel! Automatic start should only be used on equipment that
is inaccessible to personnel.
01 DISABLED: Disables the serial link
02 9600, 8, N, 2 - ENABLED WITH TIMER
03 9600, 8, N, 2 - ENABLED WITHOUT TIMER
04 9600, 8, E, 1 - ENABLED WITH TIMER
05 9600, 8, E, 1 - ENABLED WITHOUT TIMER
06 9600, 8, O, 1 - ENABLED WITH TIMER
07 9600, 8, O, 1 - ENABLED WITHOUT TIMER
P16 UNITS EDITING
This allows parameter and keypad speed editing in whole units or tenths of units above 100.
Below 100, the value can always be changed by tenths of units.
01 TENTHS OF UNITS: The value can always be changed by tenths of units (up to a value
of 1000). If the or button is pressed and held, the value will change by tenths of
units until the next whole unit is reached, and then the value will change by whole units.
Refer to Section 13.1.
02 WHOLE UNITS: The value can be changed by tenths of units until 99.9 is reached.
Above 99.9, the value will change in whole unit increments only. Below a value of 100, if
the or button is pressed and held, the value will change by tenths of units until the
next whole unit is reached, and then the value will change by whole units.
P17 ROTATION DIRECTION
01 FORWARD ONLY: The drive will only allow rotation in the forward direction. However,
JOG REVERSE (see Parameter 11) will still operate even if FORWARD ONLY is
selected.
02 FORWARD AND REVERSE: The drive will allow rotation in both directions.
P19 ACCELERATION TIME
This parameter sets the acceleration rate for all of the speed reference sources (keypad, speed
pot, 4-20 mA, 0-10 VDC, jog, MOP, and preset speeds). This setting is the time to accelerate
from 0 Hz to the BASE FREQUENCY (Parameter 27).
