SF01U 51
NOTE
The speed source displays will flash when the speed reference source is
changed while the drive is running to indicate that the new speed reference
source is active.
17.3 STATUS AND WARNING MESSAGES
SPEED SOURCE DISPLAYS
DISPLAY DESCRIPTION
CP
CONTROL PAD: Speed is set using the
and buttons on the front of the drive
EI EXTERNAL CURRENT: Speed source is a 4-20 mA signal wired to TB-25 and TB-2.
EU EXTERNAL VOLTAGE: Speed source is a 0-10 VDC signal wired to TB-5 and TB-2.
JG JOG: The drive is in Jog mode, and the speed is set by Preset Speed #2 (Parameter 32).
OP
MOP (Motor Operated Pot): Contacts wired to TB-13B and TB-13C are used to increase and decrease
the drive speed.
Pr1 - Pr7 PRESET SPEEDS #1-7: Speed is set by the indicated Preset Speed (Parameters 31-37).
STATUS AND WARNING MESSAGES
DISPLAY DESCRIPTION
br DC BRAKING: The DC braking circuit is activated.
cE
"cE" will be displayed if an EPM from a drive with a previous parameter version is installed into a new
drive, and an attempt is made to change any parameter settings. The parameters cannot be changed
until the Translate function is performed (parameter 48, setting 06).
CL
CURRENT LIMIT: The output current has exceeded the CURRENT LIMIT setting (Parameter P25) and
the drive is reducing the output frequency to reduce the output current. If the drive remains in CUR-
RENT LIMIT for too long, it can trip into a CURRENT OVERLOAD fault (PF).
Er ERROR: Invalid data has been entered or an invalid command was attempted.
GE
“GE” will be displayed if an attempt is made to change the OEM default settings when the drive is
operating in the OEM mode (see Parameter 48).
GF
If “GF” is displayed when a RESET OEM is attempted, it indicates that the OEM defaults in the EPM are
corrupted. If “GF” is displayed upon power-up, it indicates that the OEM defaults and the user settings
in the EPM are corrupted. Refer to Section 13.1.
LC FAULT LOCKOUT: The drive has failed three restart attempts and requires a manual reset.
SE
SERIAL: The optional remote keypad is active as the user interface instead of the buttons on the front
of the drive. See Parameter 14 - CONTROL.
SP START PENDING: “SP” blinks during the interval between restart attempts.
DECEL OVERRIDE: The drive has stopped decelerating to avoid tripping into an HF fault due to regen-
erative energy from the motor.
