Technical data

General data and operating conditions

EDKMF2176X DE/EN/FR 4.2



H1_Daten-2176_Anschlussdaten

7 Technical data

General data and operating conditions

General data

Characteristics

z CAN1 and CAN2 disconnected from the current supply via

DC/DC converter

z CAN1 isolated from CAN2 via optocoupler

z CAN terminating resistors integrated in CAN1 and CAN2

Interface CAN bus interface

ISO/IS 11898-2 (Philips 82C251 transceiver)

Baud rate Up to 500 kBit/s

Signal propagation delay

within the repeater

Approx. 150 ns from CAN1 to CAN2,

i. e. the max. bus length decreases by approx. 30 m

Housing Plastics DIN rail housing

Ambient conditions

Climatic conditions

Storage -25 °C … +60 °C

Transport -25 °C … +70 °C

Operation -20 °C … +60 °C

Degree of pollution 2 according to EN 50178

Enclosure IP20

Mounting conditions

Mounting type Mounting on 35 × 7.5 mm DIN rail

Connection data

Connections Screw terminals

Voltage supply DC 24 V (+9 … +35 V)

Power input DC 24 V, 1.5 W typ.
