Lenze E70ACPSE0304 Series - Page 11

[mm] 1PUSH THROUGH

11
EDKE70APE060 DE/EN/FR/ES/IT 2.1
i700P011 d
a e c c1 c2 c3 d1 d2 d3 d4 d5 j11 j21
[A] [mm]
E70ACPSD0304x 30 35
340 50 25 25
-
10 10 390 15 35 90 70
E70ACPSD0604x 60 85 50
