Lenze E70ACPSE0304 Series - Connection Terminal Details; X100 Power Terminal

X100 (400 V) 2

12
EDKE70APE060 DE/EN/FR/ES/IT 2.1
2
X100 (400 V)
X100
PE
L3
L2
L1
+
+
3 PE / AC
X100
PE
L3
L2 L1
+UG -UG
i700PX103 i700S010 7

[mm
2
] [AWG] [Nm] [lb-in]
E70ACPSx0304x
0.5 ... 16 22 ... 6 1.2 ... 1.5 10.6 ... 13.3 5.5 x 1
E70ACPSx0604x
