6 Operation
Description of the display e lements
EDK82ZBC DE/EN/FR 3.1
50

H1_Bedienung-M5user2all
ExplanationMeaningDisplay

Function bar 1
 Setpoint selection via 
Not possible if password protection is active
(display = ”loC”)

Display function:
z Display user menu, memory
location 1 (C0517/1)
z Display active parameter set
Active after every mains connection

Select codes
Four-digit display of the active code 

Select subcodes
Three-digit display of the active subcode 

Change parameter value of a
code/subcode
Five-digit display of the actual value 

Display values which have more than
5 digits
H: higher-order digits
Display of ”HI”
L: lower-order digits
Display of”lo”

Function bar 2

Select parameter set 1 ... 4 for
changing
z Display of e.g. PS 2 ()
z The parameter sets can only be activated
via digital signals (configuration with
C0410)

Select node of the system bus (CAN) The selected node can be parameterised from
the current drive
 = Function is active

Select menu
The user menu is active after every
mains switching
user List of the codes in the user menu
(C0517)
all List of all codes
funCi Only specific codes for bus function
modules, e.g. INTERBUS,
PROFIBUS-DP, LECOM-B, ...
