M5 Elemente_der_Front−Elemente_hinten_E94AZKAE
Elements on the front
Pos. Description

LCD display

Left function key

Right function key
 Navigation keys 
  key
  key
Elements on the back side
Pos. Description

Lock hook

Release button
X6 RJ69 connector, connection on diagnostic interface (X6) on the basic device
