Elements
Pos. Description See
Key T1 for starting the data transmission from the card module to the
basic device (download)
36
Key T2 for starting the data transmission from the basic device to the
card module (upload)
35
Key T3 for selecting the program memory location (0 to F)
l Press the key repeatedly until the desired program memory location
appears on the 7−segment display.
Fixing screw
7−segment display
below
Status display (green)
below
Status display (yellow)
below
Status displays
Item Colour Status Notes
green
off Data of the selected program memory location are not compatible
with the basic device connected.
on Data of the selected program memory location are compatible with
the basic device connected.
yellow
off Program memory location on the memory card is unoccupied.
on Program memory location on the memory card is occupied with data.
7−segment display
Display Description
0 ... 9
Display of program memory locations 0 to 9
a ... f
Display of program memory locations 10 to 15
Rotating bar Data transmission
–
Execution of an internal calculation
r
Resetting the basic device, i.e. the control is reset to the original state
and the data are downloaded subsequently.
e1 ... e8
Error code
ef
Formatting of the memory card
