Configuration
Basic configurations
2.2.1 Changing the basic configuration
2−5
l
EDSVS9332P−EXT DE 2.0
2.2.1 Changing the basic configuration
If the basic configuration must be changed for a special application, proceed as follows:
1. Select a basic configuration via C0005 which largely meets the requirements.
2. Add functions by:
– Reconfiguring inputs and/or outputs.
– Setting parameters for function blocks. (
3−6)
– Inserting or removing function blocks. (
3−12)
) Note!
If you change the signal flow of the basic configuration, e. g. by adding function
blocks, C0005 is set to 0. The display indicates "COMMON".
