Function librar
y
Function blocks
3.5.34
Free analog display code (DISA)
3−188
l
EDSVS9332P−EXT DE 2.0
Signal
Source
Note
Name
T
ype
DIS
DIS format
CFG
List
DISA−IN6
a
C1691/6
dec [%]
C1690/6
1
−
C1692/6
dec
C1693/6
hex
DISA−IN7
a
C1691/7
dec [%]
C1690/7
1
−
C1692/7
dec
C1693/7
hex
DISA−IN8
a
C1691/8
dec [%]
C1690/8
1
−
C1692/8
dec
C1693/8
hex
DISA−IN9
a
C1691/9
dec [%]
C1690/9
1
−
C1692/9
dec
C1693/9
hex
DISA−IN10
a
C1691/10
dec [%]
C1690/10
1
−
C1692/10
dec
C1693/10
hex
215
217
