Application examples
4.2 Example 2: Spray nozzle control
4−9
l
EDSVS9332P−EXT DE 2.0
Adaptation to the example by extending the basic configuration
Please establish the following connections:
DIGOUT 1 (terminal X5/A1 ´ SP1−STAT1
DIGOUT 2 (terminal X5/A2 ´ SP1−STAT2
Please observe:
l Description of the function block SP1
l GDC mask (if the program is used)
l Operating Instructions/Manual: Chapter ’Commissioning’
