Torque plates
Torque support is usually provided by means of the foot or ange.
The integrated torque plate is another simple possibility. In this case, torque support is
provided only via one point and is suitable for sha-mounted gearboxes, among other things.
Moreover, suitable rubber buers ensure stress-free installaon and absorb any slight
impacts.
Rubber buer for torque plate
-
-

-
-




-
!-
  

"-
#
$-
- -
 
 
%&-


  
  




-










  
  
 





 







Gearboxes Dimensions
d D d
5
c c
6
c
7
mm mm mm mm mm mm
g500-S130 11.0 30.0 30 12.0 2.50 45.0
g500-S220 11.0 30.0 30 12.0 2.50 45.0
g500-S400 13.0 40,0 37 12.0 3.00 49.0
g500-S660 13.0 40,0 37 12.0 3.00 52.0
g500-S950 13.0 40,0 37 12.0 3.00 56.0
g500-S2100 17.0 50.0 50 24.0 3.00 85.0
g500-S3100 21.0 60.0 60 24.0 4.00 94.0
g500-S4500 26.0 72.0 72 24.0 5.00 98.0
