Lenze G7 Series Mounting And Switch-On Instructions

Product informaon
Idencaon of the products
Nameplates
The nameplate is aached to the motor.
l
DE
2
10.1
8.2
10.2
7.7
10.3
7.8
10.4 8.3
9
10
8.1
18
14
3 7.6
12.1
4
13
7.3
7.4 7.5
16
11.1
11
7.2
15
19
1
12.2
12.3
11.2 11.3
7.1
17
5.7
5.9
5.8
5.4
Pos. Contents Pos. Contents
1 Manufacturer/producon locaon 9 Encoder type designaon
2 Motor type/standard 10 Brake data
3 Gearbox type 10.1 Brake type
4 Motor type 10.2 AC/DC brake voltage
5.4 Rao (gearbox) 10.3 Performance
5.7 Load capacity (gearbox) 10.4 Braking torque
5.8 Output speed (geared motor) 11 Fan specicaons
5.9 Output torque (geared motor)t 11.1 AC/DC fan voltage
7.1 Rated voltage/motor voltage 11.2 Rated frequency
7.2 Rated current/motor current 11.3 Electrical power input
7.3 Rated power/motor power 12.1 Material number
7.4 Output torque (motor) 12.2 Serial number
7.5 Motor speed [rpm] 12.3 Year of manufacture/week of manufacture
7.6 Motor code for controller parameterizaon (C86 Y 1.
Frequency)
13 Bar code
7.7 Rated frequency 14 Permissible ambient temperature
7.8 Cos phi 1. Frequency 15 Weight
8.1 Temperature class (motor) 16 UL le number
8.2 Degree of protecon (motor) 17 Conformity/approvals
8.3 Motor protecon 18 Connuous standsll torque M
0
[Nm]
19 Addional customer data
Product informaon
Idencaon of the products
Nameplates
10
