Product extensions
Mounng instrucons for shrink disc cover
NOTICE
▶
The loosely enclosed cover is mounted as a protecon against accidental contact with the
shrink disc.
Gearboxes G50AB45 ... G50BB182
X
X
Press the cover with integrated mounng pins into the bore holes on the housing ange
Gearboxes G50BB215 ... G50BB243
X
1
2
3
X
1 Shrink disc cover
2 Cheese head screw
3 Reducing bush
1.
Screw reducing bushes (3) into the threaded holes on the housing ange so that they are
ush using a screwdriver.
2.
Fasten the cover over the reducing bushes (3) using cheese head screws (2).
Mounng instrucons for hose-proof hollow sha cover
NOTICE
▶
The loosely enclosed hollow sha cover is ed to seal the hollow sha bore.
Mechanical installaon
Mounng
Product extensions
30
