Lenze G7 Series Mounting And Switch-On Instructions

A
A
X
1
2
4
A-A
X
1 Hollow sha cover
2 Cheese head screw
4 Flat gasket
1.
Place at gasket (4) between the housing ange and the hollow sha cover (1).
2.
Fasten the hollow sha cover (1) with cheese head screws (2) to the housing ange.
Torque plate mounng
NOTICE
Impermissible load caused by incorrect mounng
▶
Support the socket of the torque plate at both ends.
▶
Check the socket’s axial clearance aer mounng.
▶
In the case of a knee lever design, transfer the force at right angles to the torque plate, if
possible (90 ° ±20°).
▶
Solvents, oils, greases and fuels damage the rubber elements. Avoid contact!
Mechanical installaon
Mounng
Product extensions
31
