Product code feedbacks
Example AS 1024 - 8 V - K 2
Meaning Variant Product code
Product family Resolver RS
Resolver for safety funcon RV
Incremental encoder IG
Incremental encoder with commutaon
signal
IK
Absolute value encoder, singleturn AS
Absolute value encoder, multurn AM
Number 2-pole Resolver for servo motors 0
2-pole Resolver for three-phase AC
motors
1
Number of pole pairs for resolvers 2
3
4
...
Number of bits, steps or increments per
revoluon
20
32
128
512
1024
2048
...
Supply voltage 5 V
8 V
15 V
24 V
...
Interface or signal level Standard
TTL T
HTL (for incremental encoders) H
Hiperface (for absolute value encoders) H
EnDat E
SinCos 1 Vss S
Digital D
For safety funcon
TTL U
HTL (for incremental encoders) K
Hiperface (for absolute value encoders) K
EnDat F
SinCos 1 Vss V
Digital D
Safety Integrity Level (SIL) 1
2
3
4
Product informaon
Idencaon of the products
Product codes
13
