8.2.6 Lubricant amounts for combinable mounting positions
For the gearbox sizes 03 ...05 a combination of different mounting positions with
amounts of lubricant to suit are permissible as per the following tables.
Advantage:
Easier logistics for users who use gearboxes in different mounting positions.
Disadvantage:
On some gearboxes more lubricant is necessary in the gearbox than is necessary
technically. As a result a higher internal pressure is produced.
Helical gearbox GST04 ... 05-1; V
All types V except for VC
Mounting position GST04 GST05
A 0.10 0.20
BD 0.35 0.60
CEF 0.25 0.35
Type VC
AC 0.15 0.20
BD 0.35 0.50
EF 0.20 0.30
Helical gearbox GST03 ... 05-2; V
All types except for VC
Mounting position GST03 GST04 GST05
ABCDEF 0.20 --- ---
AEF
---
0.35 0.55
BC 0.50 0.85
D 0.55 1.0
Type VC
ABCDEF 0.17 --- ---
AEF
---
0.35 0.45
BC 0.45 0.70
D 0.60 0.95
Shaft-mounted helical gearbox GFL04 ... 05-2; V
Types VR;VL
Mounting position GFL04 GFL05
ABE 0.7 1.4
CD 1.0 1.7
F 0.3 0.7
Type VK
ABE 0.8 1.4
CD 1.1 1.7
F 0.35 0.7
