Lenze L-force E84AVSCE StateLine C Series User Manual

X100 (400 V) 20.37  3.0 kW

9
EDK84VSCE222 DE/EN/FR/ES/IT 7.2
X100 (400 V)
0.37  3.0 kW
X100 − TN, TT
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1…F3
K
Z
PE
L3
L1
+UG -UG
L2
X100
8400GG005 8400GG007
X100 − IT
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1…F3
K
PE
L3
L1
+UG
-UG
L2
X100
8400GG006 8400GG008
F L1, L2, L3 PE
EN 60204 UL
[A] [A] [A] [A] [mm
2
]
[AWG]
[mm] [Nm]
[lb−in]
[mm
2
]
[AWG]
[mm] [Nm]
[lb−in]
E84AVSCE3714 6 C6 6 C6 6 6
1 ... 2.5
18 ... 12
7
0.5
4.4
1 ... 6
18 ... 10
10
1.7
15
E84AVSCE5514 6 C6 6 C6 6 6
E84AVSCE7514 6 C6 6 C6 6 6
E84AVSCE1124 6 C6 10 C10 10 10
1 ... 2.5
18 ... 12
7
0.5
4.4
1 ... 6
18 ... 10
10
1.7
15
E84AVSCE1524 6 C6 10 C10 10 10
E84AVSCE2224 10 C10 10 C10 10 10
E84AVSCE3024xxS 10 C10 16 C16 15 15
