Mechanical installation
Mounting steps
5
EDKRBM001 DE/EN/FR 6.1
41
l
H1_MechINS−mInstall
5 Mechanical installation
Mounting steps
How to mount the brake resistor:
1. Select a suitable mounting location.
– The mounting location must always ensure the
operating conditions mentioned in the technical data; if
required, additional measures must be taken.
– Ensure unimpeded air circulation for heat dissipation.
2. Screw down the brake resistor at the mounting location.
– The mounting location and the mounting material must
ensure the permanent mechanical connection.
