X3, X4 6HighLine
16
EDK84VHCE453 DE/EN/FR/ES/IT 1.3
X3, X4
X3
GND-A
X3
A2I
O2I
A2U
O2U
A1I
O1I
A1U
O1U
AR
GA
+10 V/
10 mA
0...10V
1k ... 10k
0 ... 10 V
"
8400HLC050 8400HLC012
X4
24O
DC 24 V
(+19.2...+28.8 V)
X4
DO1DO2
DO3
GO
GND-O
8400HLC046 8400HLC045
