Identification
Product key
3 Product description
Feedback system
R esolver/enco der П П E
Гд1
] с ] с ]
[AJ
LsJ
LVJ
Legend for the product key
EN
S Type
RS Resolver
RV Resolver ’’safety”
IG Incremental encoder
IK Incremental encoder with commutation signal
SFC Singleturn absolute value encoder
AM Multiturn absolute value encoder
[g Number
1 2-pole resolver for three-phase AC motors
2, 3, 4... Number of pole pairs for resolvers
32, 128, 512, Number of steps / increments per revolution
1024, 2048, ...
[§ Voltage
5 V, 8 V, 15 V, Medium supply voltage
24 V, ...
D Interface or signal level
Standard
T TTL
H HTL (for incremental encoders)
H Hiperface (for absolute value encoders)
E EnDat
S sin/cos 1 Vss
for safety function Safety integration level (SIL)
U TTL
K HTL (for incremental encoders)
K Hiperface (for absolute value encoders)
1; 2; 3; 4
F EnDat
V sin/cos 1 Vss
Exam ple of a com plete encoder name:
AS1024-8V-K2 = Singleturn absolute value encoder w ith safety function;
1024 periods per revolution; 8V supply voltage;
Hiperface interface; safety integration level SIL2
If feedback system s for safety functions are used, the m anufacturer's
docum entation must be observed!
