COMMISSIONING MANUAL
POWERDRIVE MD
Variable speed drive
MENUS AND DIAGRAMS IN ADVANCED SET UP MODE
LEROY-SOMER
3871 en - 2011.05 / h
5.12 - Menu 11: General drive set up
5.12.1 - Menu 11 diagram
Drive software version
User drive mode
Drive current rating
Serial mode
Drive voltage rating
Drive identification code
• Drive configuration
• Miscellaneous
Parameter 46 assignment
• Menu 0 configuration
• Serial link
Parameter cloning
Quick setup menu access
• Parameter setting
Factory settings
Motor parameter select
Save parameters
Menu to be saved
Communication type between drives
Serial address
Baud rate
Min comms transmit delay
Parity, number of stop bits
Parameter 47 assignment
Parameter 48 assignment
Parameter 49 assignment
Parameter 50 assignment
Parameter 51 assignment
Parameter 52 assignment
Parameter 53 assignment
Parameter 54 assignment
Parameter 55 assignment
Parameter 56 assignment
Parameter 57 assignment
Parameter 58 assignment
Parameter 59 assignment
Parameter 60 assignment
Parameter 61 assignment
Parameter 62 assignment
Parameter 63 assignment
Parameter 64 assignment
Parameter 65 assignment
Advanced menu access code
11.29
11.24
11.33
11.31 11.60
11.32
11.11
11.12
11.13
11.14
11.15
11.16
11.17
11.18
11.19
11.20
11.61
11.01
11.02
11.03
11.04
11.05
11.06
11.07
11.08
11.09
11.10
11.42
11.44
11.43
11.45
11.64
11.65
11.66
11.23
11.25
11.26
11.27
