32
1. Turn the focus ring counterclockwise (when viewing though the
eyepiece) until it stops.
2. Turn the focus ring clockwise until the “10m” mark aligns with the
indicator mark on the bell of the scope.
3. From this point, all readings of the focus ring are in numerical
order when the ring is turned clockwise from the shooting
position.
4. Adjust the ring as you would a standard adjustable objective
model.
INSTALLING A LENS ATTACHMENT
Many Leupold scopes offer threaded objective and eyepiece rings to
allow for the attachment of lens covers and a variety of Alumina
®
accessories. These attachments thread directly into the objective or
eyepiece rings. Turn until finger tight – do not over tighten.
To adjust the parallax distance,
turn the focus ring.
