3
FUNCTION 3: 1
ST
TARGET MODE
1
st
Target Mode is used to display the distance
to the closest object when more than one
object may be hit by the beam. Multiple
objects will often return an average
distance. 1
st
Target Mode ensures an
accurate reading on the closest object.
Last Target Mode is automatically disabled
while 1st Target Mode is activated.
FUNCTION 4: LAST TARGET MODE
This mode is used to display the distance to
the farthest object when more than one
object may be read. Multiple objects
will often return an average distance.
Last Target Mode ensures an accurate
reading on the farthest object.
1st Target Mode is automatically disabled
while Last Target Mode is activated.
FUNCTION 5: METER OUTPUT
This mode displays both LOS (Line of Sight)
and TBR ranges in meters, and will
disable readings in yards or feet. TBR
is displayed with one decimal place
resolution in large numbers just above
the reticle, LOS is displayed in small
numbers above the angle readout (just
below and to the right of the reticle).
FUNCTION 6: FEET OUTPUT
This mode displays both LOS (Line of Sight)
and TBR ranges in feet, and will disable
readings in yards or meters. TBR is
displayed with one decimal place
resolution in large numbers just above
the reticle, LOS is displayed in small
numbers above the angle readout (just
below and to the right of the reticle).
FUNCTION 7: YARDS OUTPUT
This mode displays both LOS (Line of Sight)
and TBR ranges in yards, and will disable
readings in meters or feet. TBR is
displayed (no decimal place resolution)
in large numbers just above the reticle,
LOS is displayed in small numbers above
the angle readout (just below and to the
right of the reticle).
FUNCTION 8: LINE OF SIGHT OUTPUT
This mode, when activated, provides the straight
line distance to the target. The output is
displayed in smaller numbers just below
and to the right of the reticle.
NOTE: On the RX-I model, LOS is
displayed in large numbers above the
reticle (in the TBR position).
FUNCTION 9: FAHRENHEIT OUTPUT
When activated, this mode displays the air
temperature
in Fahrenheit. If Fahrenheit
is activated, the Celsius Mode and LOS
(Line of Sight) range will be disabled.
The output is displayed in smaller
numbers just below
and to the right of
the reticle. (Not available on RX-IV Boone
and Crockett
™
.)
FUNCTION 10: CELSIUS OUTPUT
When activated, this mode displays the
air temperature in Celsius. If Celsius is
activated, the Fahrenheit Mode and
LOS (Line of Sight) range will be
disabled. The output is displayed in
smaller numbers just below and to the
right of the reticle. (Not available on
RX-IV Boone and Crockett.)
FUNCTION 11: DIGITAL COMPASS MODE
(RX-IV ONLY)
When activated, the compass heading will
be displayed in larger numbers above the
reticle. If the Digital Compass Mode
is activated, the True Ballistic Range
(TBR) will be disabled. The compass will
perform accurately even if tilted for
viewing targets uphill or downhill,
at angles as severe as 30º. Tilt compensation
is accomplished via a sophisticated computer-processed algorithm
that incorporates both the compass and inclinometer readings.
NOTE: Calibration of the compass must be performed when the
rangefinder is initially used and anytime it is moved to a new
region — see Function 17 for calibration procedure.
