EN
24
FUNCTIONS
Target surfaces: Measuring errors can occur when
measuring to colourless liquids, glass, styrofoam or
semi-permeable surfaces or when aiming at hight
gloss surfaces. Against dark surfaces the measuring
time increases.
Measuring single distance
Continuous measuring
3 sec
Aim active laser at target.
The largest
and smallest
measured value
appear above it.
Stops continuous
measuring
Modes
Press button
to select mode
clockwise
Note:
1. The system default measurement start at the
single distance measuring.
2. Bluetooth and Brightness are inside of the
ICON “ “
3. The selection of specic Pythagoras, Bluetooth,
Brightness etc. is the same way of modes
selection by clockwise or counterclockwise.
Press button to select
mode counterclockwise
Press button to start the
mode selected
