LevelOne 55051007 - Specification

6
Specification:
IEEE Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE802.3af for POE
IEEE802.3at for POE+
Network Connector :
1xRJ-45 10/100/1000BaseT(X) Data
1xRJ-45 10/100/1000BaseT(X) Data with POE
Output power
Network Cable
UTP/STP above Cat.5e Cable
EIA/TIA-568 10-ohm (100m)
Protocol
CSMA/CD
LED
PW1(power 1) Green: ON- power good, OFF-
power failed
PW2(power 2) Green: ON- power good, OFF-
power failed
POE: ON- POE Normal working,
FLASH- Overload,
OFF- NO POE power detected
POE Pin Assignment
Mode A model, V+, V+, V-, V- for pin 1, 2, 3, 6
Reverse polarity protection
Present
Overload current protection
Present
Power Supply
2 Redundant power source
12V~56V VDC Power Input
Power Consumption
1 W@12/24/48 VDC full load, Without POE
POE power
Maximum POE power 36watts at 12/24/48VDC
input
