IES-0510 User Manual Page 11
Specifications
Industrial Compact Switch
10/100Base-TX auto-negotiating ports with RJ-45 connectors,
100Base-FX fiber ports
Applicable Standards
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX/FX
IEEE802.3az Energy Efficient Ethernet
IEEE802.1p Quality of Series (QoS)
Switching Method
Store-and-Forward
Forwarding Rate
10Base-T:
100Base-TX/FX:
10 / 20Mbps half / full-duplex
100 / 200Mbps half / full-duplex
Performance
148,80pps for 10Mbps
148,810pps for 100Mbps
Cable
10Base-T:
100Base-TX:
100Base-FX:
2-pair UTP/STP Cat. 3, 4, 5
2-pair UTP/STP Cat. 5
Up to 100m (328ft)
MMF (50 or 62.5μm), SMF (9 or10μm)
LED Indicators
Per unit – Power status (PWR)
Per port – 10/100TX or 100FX -
LNK/ACT (Green), 100 (Yellow)
Dimensions
26mm (W) × 70mm (D) × 110mm (H)
(1.02” (W) × 2.76” (D) × 4.33” (H))
Net Weight
0.2Kg (0.44lb.)
Power
Terminal Block: 12-48VDC
Operating Voltage &
Max. Current
Consumption
0.2A @ 12VDC, 0.1A @ 24VDC, 0.05A @ 48VDC
Power Consumption
2.4W Max.
Operating Temperature
-10℃ to 60℃ (14℉ to 140℉)
Storage Temperature
-25℃ to 85℃ (-13℉ to 185℉)
Humidity
5%-95% non-condensing
Safety
UL60950-1, EN60950-1, IEC60950-1
EMI
FCC Part 15, Class A
EN61000-6-3:
EN55022, EN61000-3-2, EN61000-3-3
EMS
EN61000-6-2:
EN61000-4-2 (ESD Standard)
EN61000-4-3 (Radiated RFI Standards)
EN61000-4-4 (Burst Standards)
EN61000-4-5 (Surge Standards)
EN61000-4-6 (Induced RFI Standards)
EN61000-4-8 (Magnetic Field Standards)
EN61000-4-11 (Voltage Dips Standards)
Environmental Test
Compliance
IEC60068-2-6 Fc (Vibration Resistance)
IEC60068-2-27 Ea (Shock)
IEC60068-2-32 Ed (Free Fall)
