Specification:
IEEE Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3z 1000Base-X Gigabit Ethernet
IEEE802.3x Flow Control and Back Pressure,
IEEE802.3af for POE
IEEE802.3at for POE+
Switch Architecture
Back-plane (Switching Fabric): 8-Gbps
Data Processing
Store and Forward
Flow Control:
IEEE 802.3x Flow Control and Back Pressure
Jumbo Frame
10KB
MAC address Table Size
8K
Packet Buffer Size
1Mbits
Network Connector:
3 x RJ-45 10/100/1000BaseT(X) auto negotiation,
2 x Gigabit 30Watts PoE+ 802.3at/af PSE port
1 x 10/100/1000M TX
1 x 100/1000M SFP
Auto MDI/MDI-X function, Full/Half duplex
Network Cable
UTP/STP Cat.5e Cable or above
EIA/TIA-568 10-ohm (100m)
Protocol
CSMA/CD
LED
PW1(Power 1) Green,
PW2(Power 2) Green,
PW3(Power 3) Amber, for external power adapter
RLY (Relay) Amber
TX/RJ-45 port:
Lnk (Link/Active) Green/Flashing
PoE Amber
SFP port:
F4 (Link/Active) Green
DIP Switch
DIP1: OFF: Port 4 SFP 1000M
ON: Port 4 SFP 100M
DIP2: Reserve
Reserve polarity protection
Present
Overload current protection
Present
Power Supply
Redundant Dual DC 48V-56V Power Input
PoE input 48-56VDC
Power Consumption
4.0 W@48 VDC full load, Without POE
Max total power 65 Watts
Alarm Relay Contact
Relay outputs with current carrying capacity of 1 A
