LevelOne IGP-0401 - Terminal Blocks and Environmental Specifications; Removable Terminal Block Features; Operating and Storage Environment; Certifications and Compliance

5
@24VDC,
Relay in open circuit mode when 2 powers are
connected. in short circuit mode when only one power
supply is connected
Removable Terminal Block
Provide 2 Redundant power, Alarm relay contact ,6 Pin
Wire range: 0.34mm^2 to 2.5mm^2
Solid wire (AWG):12-24/14-22
Stranded wire(AWG): 12-24/14-22
Torque:5lb-In/0.5Nm/0.56Nm
Wire Strip length: 7-8mm
Power DIN
For 110VAC/240VAC external power adapter, 4 pin high
current with lock type
Operating Temperature
-40 ℃ ~75 ℃ fully tested.
Operating Humidity
5% to 95% (Non-condensing)
Storage Temperature
-40 ℃ ~85 ℃
MTBF (mean time between failure)
>500,000 hrs. (MIL-HDBK-217F) at 25°C
Housing
Rugged Metal, IP30 Protection
Case Dimension (W X D X H)
142 x 36.2 x 105 mm (L x W x D)
Installation mounting
DIN Rail mounting and Wall Mounting
Certifications
EN55022/24
ITE equipment
EN55011
Industrial, Scientific and Medical (ISM) equipment
Safety
IEC EN60950-1
EMC/EMS
CE, FCC, VCCI
EMI
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
EN 50155 / EN 60068-2-6
Vibration
EN 50155 / EN 60068-2-27
Shock
EN 50155 / EN 60068-2-32
Free Fall
